DC-DC150W Boost Converter 10-32V to 12-35V Step Up Module Adjustable Power Voltage

Description

Specification:

• Input voltage: DC 10V-32V
• Output voltage: DC12V-35V(adjustable)
• Input Current: 16A (MAX) (Please enhance heat dissipation if more than 10A)
• Output Current: 10A (MAX)
• Output power: natural cooling 100W (MAX), strengthening cooling 150W (MAX) real power
• Module Properties: non-isolated step-up module (BOOST)
• Size: 65mm x 35mm x 21mm

FEATURES:

• Easy to drive 65W 90W dual-core notebook. Use a 12V battery drive 19V 3.42A notebook, the module temperature about 45℃
• Conversion efficiency: 94% (For reference: when Input 19V 2.5AOutput 16V)
• Output Ripple: 2% (MAX) 20M-bandwidth
• Operating Temperature: Industrial (-40℃ ℃) (ambient temperature exceeds 40°c, lower power use, or to enhance heat dissipation)
• Full load temperature rise: 45℃
• No-load current: 25mA typical
• Voltage regulation: ± 0.5%
• Dynamic response speed: 5% 200uS
• Short circuit protection: None (Please Install fuses and protection circuits at Input port.)
• Input Reverse Polarity Protection: None (please comply with are verse protection or connect a diode at input parts)
